Instruction Guide - Toyota RAV4 2019+ SnapPlate
Installation
-
![Three black mounting brackets arranged horizontally on a white background, each with a central rectangular component and multiple screw holes for attachment.]()
Step 1
Plate mounts are shipped in the high position by default. If you prefer a different position, follow the Plate Height Adjustment instructions ☝️ to adjust before continuing.
-
![Hand holding a license plate frame labeled California SNAPPLATE everyamp.com as a screwdriver tightens a screw.]()
Step 2
Install your license plate using four of the included black or silver torx security screws.
-
![Hand adjusting a black bracket with an arrow indicating rotation direction.]()
Step 3
Press the left side of the actuator to rotate the latches open.
-
![Close-up of a black plastic component labeled SNAPPLATE RAV4, featuring a narrow central gap aligned with an orange arrow.]()
Step 4
Insert into the center of the grille with the vertical grille slat aligned with the vertical opening in the SnapPlate.
-
![A hand turns a black circular knob on a piece of metal equipment, with an orange arrow indicating the direction of rotation.]()
Step 5
Press the bottom side of the actuator to rotate it into the locked position.
If the actuator is too difficult to fully close or the SnapPlate feels loose on the grille after it is closed, adjust the rotating latches following the Grille Depth Adjustment instructions. ☝️ -
![Close-up of a black metal frame with a circular detail highlighted by an orange ring, showing screws and flat surfaces.]()
Step 6
Make sure the actuator is flush with SnapPlate body to ensure it is locked in place with the magnets engaged.
-
![Close-up of a screwdriver adjusting a bolt on a black 3D-printed frame, with an orange circle highlighting the area being adjusted.]()
Step 7
Optionally, install a black anti-theft security screw in the hole on the right side.
Note: Take care to not overtighten the screw, it only needs to be snug to work. -
![A hand adjusts a black 3D printer component with rods and a gear mechanism against a white background.]()
Step 8
Don’t forget to remove SnapPlates for automated car washes. Most touchless washes are fine, but better to be on the safe side!
Plate Height Adjustment
-
![Three black mounting brackets arranged horizontally on a white background, each with a central rectangular component and multiple screw holes for attachment.]()
Step 1
RAV4 SnapPlates ship in the high position by default, but are adjustable into 3 possible positions.
We recommend high for the best airflow to the grille. -
![A hand uses a yellow screwdriver to tighten screws on a black mounting bracket. Arrows indicate the direction to turn the screws.]()
Step 2
Remove the two screws holding the plate mount to the body.
- For installation in the high position go to Step 3.
- For installation in the center position go to Step 4.
- For installation in the low position go to Step 5. -
![A hand uses a yellow screwdriver to adjust a black mounting bracket. The bracket has two elongated arms with arrows indicating a pivot movement.]()
Step 3 (High)
Position the plate mount with the bottom holes lined up with the body and install screws.
- Go to Step 6
-
![A hand uses a screwdriver to attach a black mount bracket with two screws.]()
Step 4 (Center)
Position the plate mount with middle holes aligned with the body. Install screws.
- Go to Step 6
-
![A hand uses a yellow screwdriver to tighten a screw on a black metal frame with orange arrows indicating rotation.]()
Step 5 (Low)
Rotate the plate mount 180 degrees and align the holes with the body. Install screws.
- Go to Step 6
-
![Hand holding a license plate frame labeled California SNAPPLATE everyamp.com as a screwdriver tightens a screw.]()
Step 6
If not already installed, install the license plate using four of the included black or silver security screws.
Grille Depth Adjustment
-
![An orange plastic handle and a dual-ended metal screwdriver bit are placed on a white background.]()
Step 1
Remove the T10/T25 bit from the screwdriver handle and reinstall with the T10 bit facing out.
-
![Close-up of a black mechanical part with screws, mounted on a T-shaped bracket with multiple holes for attachment.]()
Step 2
Locate the T10 torx screws in the center of each rotating latch.
- Go to Step 3 to loosen latches
- Go to Step 4 to tighten latches
-
![A screwdriver is used to adjust screws on a black plastic contraption with labeled parts, surrounded by orange directional arrows.]()
Step 3
Turn each screw counterclockwise (lefty loosey) 1/2 turn to loosen the latches by 0.25mm. Pull each latch with your fingers to make sure they are extended and then try the fit on the grille.
Repeat up to four times (two full turns) as needed.
Important! Contact support before proceeding past two turns. If loosened more than two turns, the SnapPlate could become stuck in the grille and it may be very difficult to remove. -
![A tool is adjusting a black mechanical device with multiple components, featuring orange arrows indicating rotation direction.]()
Step 4
Turn each screw clockwise (righty tighty) 1/2 turn to tighten the latches by 0.25mm and try the fit on the grille.
- Repeat as needed.
